Hydraulic Wheel Digger With Yuchai Supercharged Engine And Plunger Pump

I'm Online Chat Now

Hydraulic Wheel Digger With Yuchai Supercharged Engine And Plunger Pump

Hydraulic Wheel Digger With Yuchai Supercharged Engine And Plunger Pump
Hydraulic Wheel Digger With Yuchai Supercharged Engine And Plunger Pump Hydraulic Wheel Digger With Yuchai Supercharged Engine And Plunger Pump Hydraulic Wheel Digger With Yuchai Supercharged Engine And Plunger Pump Hydraulic Wheel Digger With Yuchai Supercharged Engine And Plunger Pump

Large Image :  Hydraulic Wheel Digger With Yuchai Supercharged Engine And Plunger Pump

Product Details:
Place of Origin: China
Brand Name: Wenyang Machinery
Certification: ISO ,CE
Model Number: WY75W-9
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: 2 sets/40HQ
Delivery Time: 20 days
Detailed Product Description
Condition: New Moving Type: Wheel Excavator
Operating Weight: 6300kg Max Digging Reach: 6470mm
Max Digging Depth: 3315mm Max Digging Height: 6590mm
Max Dumping Height: 4935mm Boom Length: 3400mm
Bucket Capacity: 0.3m3
High Light:

small wheeled excavator

,

small bucket wheel excavator

0.3m3 bucket hydraulic wheel digger with Yuchai supercharged engine and plunger pump





Hydraulic Wheel Digger With Yuchai Supercharged Engine And Plunger Pump 0

Hydraulic Wheel Digger With Yuchai Supercharged Engine And Plunger Pump 1



Our company independently researched and developed the first domestic 6.5TON rubber-tyred hydraulic excavator XY75W-9 equipped with configuration of supercharged and plunger-pump in 2012,which was put into the market in 2013 .The 75w-9 is high –performance model ,which has been upgraded and improved on the base of 65W-8,with lengthened movable arm and bucket rod .It is equipped with 8 pieces of 8.25-16 tires on the finished vehicle ,which not only improves operational stability but also enhances the passing ability .The working device has been customized to improve greatly on its excavating range , height and strength on the basis of ensuring the excavating depth.



Technical data
Boom length 3400mm
Maximum digging reach 6470mm
Maximum digging depth 3315mm
Maximum digging height 6590mm
Maximum dumping height 4935mm
Minimum platform tail tuning radius 2230mm
Width of platform 1900mm
Overall width 1950mm
Machine height 2800mm
Distance from the digging arm to rotate machine 4090mm
Maximum length of transportation 5900mm
Maximum ground clearance 390mm
Maximum height for bulldozing (Optional)
Rise quantity decline quantity of bulldozing plate 350/80mm
Power 42kw/2100rpm
Machine weight 6300kg
Volume of bucket 0.3m3
Set pressure with main spill valve 22Mpa
Maximum digging force 45KN
Gradeability 59% (30)
Pressure to the ground 49Kpa
Travel speed 27km/h
Maximum traction force 60KN
Swing speed of platform 10.5rpm
Fuel tank capacity 110L
Hydraulic tank capacity 125L



Hydraulic Wheel Digger With Yuchai Supercharged Engine And Plunger Pump 2
