| Rated Capacity: | 5TON | Bucket Capacity: | 3m3 |
|---|---|---|---|
| Engine: | Weichai | Operating Weight: | 17300kg |
| Engine Power: | 162kW/2200rpm | ||
| High Light: | front end shovel loader,lonking wheel loader |
||
POWERFUL WEICHAI ENGINE
LONKING TRANSMISSION
LONKING AXLES
JOYSTICK CONTROL
AC+ROPS&FOPS CABIN
VARIETY WITH ATTACHMENT
CONVENIENT MAINTENANCE
RATED POWER:162kW/2200rpm
BUCKET CAPACITY:3.0m³
RATED PAYLOAD:5000kg
OPERATING WEIGHT:17300kg
| Model | CDM856 (Weichai) |
| Bucket Capacity(m³) | 3.0-4.2 |
| Rated Payload (kg) | 5000 |
| Rated Power(kw/rpm) | 162/2200 |
| Operating Weight (kg) | 17300 |
| Traction Force(kN) | 155 |
| Breakout Force (kN) | 170 |
| Dump Clearance at Max.Lift(mm) | 3080 |
| STANDARD EQUIPMENT | |
| WEICHAI Engine | Limited Lifting Position |
| LONKING Transmission | Standard Lift&Bucket (3.0m³) |
| Mechanical Powershift Control | ROPS&FOPS Cabin |
| LONKING Axles | Air Conditioner |
| Joystick Control(2 Spool) | Radio/MP3 |
| Automatic Leveling | LCD Display |
| OPTIONAL EQUIPMENT | |
| ZF Transmission&LONKING Axles | Quick-change Coupler |
| ZF Transmission&ZF Axles | Quick-change Bucket |
| Cold Starting (-35℃) | 3 Piece Cutting Edge,Bolt-on Type Bucket |
| Oil-bath Air Filter | Rock Bucket(3.0m³) |
| 23.5R25 ★★ L-3 TL | Enlarged Bucket(3.5m³) |
| 23.5R25 ★★ L-5 TL | Coal Bucket(4.2m³) |
| 3rd Spool for Auxiliary Function | Log Fork |
| Sliding Cabin Window | Grasping Pitchfork |
| Electric Heating Rear Window | Side Dump Bucket(2.5m³) |
| Lockable Oil Tank Cap | Marble Fork |
| Rear View Camera | Fork(Quick-change Only) |
| Pressure Testing Connector | 4in1 Bucket(Quick-change Only) |
| High Lift &Additional Counterweight | Snow Blade(Quick-change Only) |
